Gem Faceting Machine FJM-2014 with Both Faceting and Polishing Functions FJM-2014

Name: Gem Faceting Machine FJM2014 with Both Faceting and Polishing Functions FJM2014
Brand: FABLE
Price: 1 USD

Brand Name : FABLE

Model Number : FJM-2014

Place of Origin : Guangdong, China

MOQ : 1 set

Payment Terms : T/T, Western Union,paypal

Supply Ability : 500 sets/month

Delivery Time : In 7 days after payment confirmation.

Packaging Details : Carton packing.

Price : negotiation

functions : faceting and polishing

motor power : 170-180W

motor speed : 1350 r/min.

power supply : AC220V, 50-60Hz.

mainshaft speed : 2300-2800 r/min.

operation : manual availability

accessory : faceting hands

faceting dish : 15cm diameter

faceting hardness : up to 9

packing dimension : 75X40X38cm

Contact Now

New Designed Gem Faceting Machine with Both Faceting and Polishing Functions

Model number: FJM-2014

The gem lapidary machine is used for gem facet processing and grinding samples for mineral separation. Fable Faceting machine has a compact structure and reasonable coordination. It has the advantages of stable operation, good heat dissipation and low noise under high-speed operation.

1. Main functions: Faceting and Polishing the Gemstone.
2. With Faceting holder,the optional angle gauge for geting the exact faceting and angle of the gem.
3. With shaping holder for geting the good shape of the gem.
4. To Faceting the gemstone with hardness up to 9.
5. manual operation availability
6. With 10 pcs of dot sticks.
7. With a Faceting Dish and its Dia. of 150mm.
8. With 3 pcs diamond disk for Faceting polishing( 400#; 800#; 1200#)
9. With rounded tray and it's Dia. of 160 mm;
10. With the foot switch to control the speed
11. With CE certificate

Technical Parameter:

*Model	FJM-2014
*Input Voltage	AC220V,50/60HZ
*Moter Power	170-180W
*Speed of Moter	1350r/min
*Speed of Mainshaft	2300-2800r/min
*Diameter of the disk	150mm
*Angle Range	1-90 degree
*Size of Machine	600300380mm
*With vernier scale,accuracy	0.1mm
*Index wheel	96 and 64

Applications:

gemology, gem/jewellry manufacturing industry, jewellery technology school, etc
